MikroTik R11e-5HacT - High-power triple-chain miniPCIe card

MikroTik R11e-5HacT - High-power triple-chain miniPCIe card

The new AC standard is here, with up to 1.3 Gbps data rate and 256-QAM modulation, and 80 MHz channels. 802.11ac opens up new possibilities and speeds never possible before.

R11e-5HacT is our first MIMO 3x3 triple-chain 802.11ac card in miniPCIe format, perfect for any RouterBOARD with miniPCIe slot, such as RB953, RB912, RB800, BaseBox etc.

The card features built-in LED indicators for wireless mode, connection status (connected, searching, disabled), TX and RX activity and wireless signal strength - just looking at the card will help with installation and alignment.

Specifications

• Product code: R11e-5HacT
• Chipset: QCA9880
• Frequency range: 4920 - 6100 MHz (operating range limited by country regulations)
• Standards: 802.11ac
• Max. output power: 630 mW
• Format: miniPCIe
• Dimensions: 50 x 30 x 13 mm
• Connectors: 3x MMCX
• Supported channels: 20/40/80 MHz
• Features: 9 LED indicators, ESD protection
• Temperature:
• Starting:-5°C to +65°C
• Operating: -30°C to +65°C
• Max. power consumption: 5 W
